Uranium Enrichment Using Gas Centrifuges

​
cylinder radius
r
0
(cm)
10
cylinder height Z (m)
5
rotation rate Ω (rpm)
60000
number of stages n
0
Natural uranium has an isotopic composition consisting of 99.284% U238 and 0.711% U235 (plus a very small fraction of U234)[1–4]. Only the U235 isotope can undergo nuclear fission for use in nuclear reactors and weapons. For nuclear power reactors, the uranium must be enriched to approximately 3 to 5% U235. Some research reactors use enrichment to 12–20%, while nuclear weapons require at least 85% enrichment.
The most prevalent method for uranium enrichment makes use of a cascade of gas centrifuges. Uranium hexafluoride
UF
6
sublimes into a gas, referred to as "hex," at 56 ˚C (
≈330
K) under normal atmospheric pressure. Fortunately, fluorine is isotopically pure
19
F
, so that the mass difference between
238
19
U
F
6
(
M=352
) and
235
19
U
F
6
(
M=349
) is due entirely to the uranium isotopes. This Demonstration describes a simplified model of the Zippe centrifuge, developed in the years following World War II.
Gas molecules in a rotating cylinder experience a centrifugal force pushing them toward the outer wall of the cylinder. The density distribution has a form analogous to the barometer formula, for the atmospheric density in a gravitational field, specifically,
ρ(r)=ρ(0)
M
2
r
2
ω
/2RT
e
,
where
ρ
is density,
r
is the distance from the axis of the cylinder,
ω
is the angular velocity of rotation,
T
is the absolute temperature and
R
is the gas constant. The local mole fraction of U235 is given by
f(r)=
-1
1+
ρ
238
(0)
ρ
235
(0)
ΔM
2
r
2
ω
/2RT
e
,
where
ΔM=
M
238
-
M
235
=.003
kg/mol.
Typical rotor spin rates are in excess of 60,000 rpm, which corresponds to
ω=60000×2π/60≈6000
-1
sec
. With cylinder radii of the order of 10 cm, almost all the gas is flattened into a narrow shell clinging to the cylinder walls, known as the Stewartson layer.
The success of the gas centrifuge is made possible by changing the direction of enrichment from radial to axial by inducing vertical circulation of the hex between the top and bottom of the cylinder. Convection in the gas is produced by creating a temperature gradient by heating the bottom of the cylinder. As a result of the vertical circulation, the enriched hex can be withdrawn from the top of the centrifuge, while the depleted hex is drawn out from the bottom.
A single centrifuge can achieve a separation factor in the range of 1.2 to 1.5, meaning that the fraction of U235 is enhanced (from its beginning value of 0.007) by this factor. Clearly, to produce the enrichment required for reactor use, a cascade of connected centrifuges must be used, with the enriched output from one stage fed into a successive stage. The end product might require as many as 20 stages. There are usually multiple banks of centrifuges for each stage, to increase the total output of enriched product (see photo in Details).
The graphic is a highly idealized and simplified representation of a gas centrifuge. Hex at some intermediate stage of enrichment is fed into the inlet F, while the outlets P and W withdraw the product (U235 enriched hex) and the waste (U235 depleted hex), respectively.
The pie chart on the right shows the isotopic composition of the uranium after
n
centrifuge stages.

Details

A simplified model for the operation of the centrifuge gives
x(n)
, the U235 mole fraction at stage
n
, as a recurrence relation (unpublished work by the author, at Los Alamos):
x(n)=
1+
1
x(n-1)
-1
ΔM
2
r
0
2
ω
/2RT
e
1+
1
x(n-1)
-1
ΔM
2
r
1
2
ω
/2RT
e
x(n-1)
.
Here
r
0
is the radius of the centrifuge,
Z
is its height, and
r
1
=
λ
Z
r
0
, with
λ≈2.77m
. For larger values of
n
, say
n>10
, the recurrence computation becomes time consuming. But a good approximation to
x(n)
can be constructed as a sigmoid curve with
x(n)≈
n
ΔM
2
r
0
-
2
r
1
2
ω
/2RT
e
x(0)
initially, merging into a function such that
x(n)1
as
n∞
.
Cascade of gas centrifuges used to produce enriched uranium. US gas centrifuge plant in Piketon, Ohio: US Department of Energy (Public domain), via Wikimedia.

References

[1] R. S. Kemp, "Gas Centrifuge Theory and Development: A Review of U.S. Programs," Science and Global Security, 17(1), 2009 pp. 1–19. doi:10.1080/08929880802335816.
[2] S. Whitley, "Review of the Gas Centrifuge until 1962. Part I: Principles of Separation Physics," Reviews of Modern Physics, 56(1), 1984 pp. 41–66. doi:10.1103/RevModPhys.56.41.
[3] D. R. Olander, "The Gas Centrifuge," Scientific American, 239(2), 1978 pp. 37–43. www.jstor.org/stable/24960352.
[4] Wikimedia. "Gas Centrifuge Cascade." (Aug 27, 2018) upload.wikimedia.org/wikipedia/commons/6/69/Gas_centrifuge_cascade.jpg.
