Euclidean Vector Introduction

A vector is a quantity that has both a magnitude and direction.

Vector Basics

Let’s start by making a vector in the 2-D Cartesian plane.
◼
Draw the vector v starting at point (0,0) and ending at point (1,1).
In[6]:=
Graphics[{Arrow[{{0,0},{1,1}}]},AxesTrue]
Out[6]=
This vector describes a quantity that is pointed in the northeast direction. Its norm, or magnitude, is defined as
2
(
x
2
-
x
1
)
+
2
(
y
2
-
y
1
)
.
◼
Calculate the norm of v, or Norm[v].
In[408]:=
Sqrt[(1-0)^2+(1-0)^2]
Out[408]=
2
Thus the magnitude of this vector v (||v||) can be said to be
2
. This vector v would be written as {1,1} because it moves over 1 unit in the x direction and up 1 unit in the y direction.

Unit Vectors

Unit vectors are vectors that have a direction but have a magnitude of 1.
◼
Show the unit vector i in blue and j in red.
In[103]:=
Graphics[{Blue,Thick,Arrow[{{0,0},{1,0}}],Red,Arrow[{{0,0},{0,1}}]},AxesTrue]
Out[103]=
The vector {1,1} could also be written as i + j where both terms have a coefficient of 1. Unit vector i corresponds to the x-component (horizontal) while j corresponds to the y-component (vertical).

Vector Decomposition

In order to begin vector operations, we need to know how to get its components.
◼
Find the vertical component of the vector {1,1}.
In[69]:=
Norm[{1,1}]*Sin[Pi/4]
Out[69]=
1
Using simple trigonometry by viewing the vector as a triangle’s hypotenuse, we can obtain the vertical component.
◼
Display the vertical component graphically.
In[74]:=
Graphics[{Arrow[{{0,0},{1,1}}],Red,Arrow[{{1,0},{1,1}}]},AxesTrue]
Out[74]=
The horizontal component is very similar.
In[76]:=
Norm[{1,1}]*Cos[Pi/4]
Out[76]=
1
◼
Display the horizontal component graphically.
In[104]:=
Graphics[{Arrow[{{0,0},{1,1}}],Red,Thick,Arrow[{{0,0},{1,0}}]},AxesTrue]
Out[104]=
◼
Create your own vector and look at its components.
In[10]:=
Manipulate[​​Graphics[{​​Arrow[{{0,0},{a,b}}],​​Red,Thick,Arrow[{{0,0},{a,0}}],​​Blue,Arrow[{{a,0},{a,b}}]},​​PlotRange{{-10,10},{-10,10}},AxesTrue,​​Epilog{​​Text[Style[a,Red,FontSize20],{5,5}],​​Text[Style[b,Blue,FontSize20],{5,6}],​​Text[Style[Norm[{a,b}],Black,FontSize20],{5,7}]}],​​{a,-10,10,0.1},{b,-10,10,0.1}]
Out[10]=
​
a
b

Vector Addition and Subtraction

Just like scalars, which have only a magnitude and no direction, vectors can undergo operations such as addition and subtraction.
◼
Add the two vectors {3,2} and {0,4} together.
In a vector addition, individual components are added. We get {3,6} from {3+0, 2+4}. Subtraction works the same way.
◼
Subtract the vector {5,2} from the vector {1,3}.

Vector Multiplication: Dot Product

Multiplication of vectors is a bit more complex. We’ll start with the dot product. The result of a dot product is not a vector but instead is a scalar with just a magnitude and no direction. What it shows is the projection of vector one along vector two.
◼
Take the dot product of the vectors {4,1} and {2,1}.
It is obtained from 1*2 + 1*0.
◼
Without knowing the components of a vector, the dot product can be obtained by:
This is ||v||*||u||*cos(θ) where v and u are vectors and θ is the angle between them.
◼
Let’s look at it graphically:
From this we can easily see that there is no projection of the first vector onto the second vector that is along the y-axis, which is why in our dot product 1*2 + 1*0, the second term results in a 0.
◼
Like scalar multiplication, order does not matter for a dot product.

Vectors in 3-D

Just as vectors can exist in two dimensions, so they can exist in three dimensions.
◼
Draw the vector {1,1,1}.
◼
Find the norm of the vector v = {1,2,3}.
In three dimensions, addition and taking the dot product work the exact same way but with an added term. Additionally, the unit vector in the third dimension is k.
◼
Make your own 3-D vector.

Vector Multiplication: Cross Product

◼
The cross product takes two vectors and results in a vector that is orthogonal to both.
This time the output is a vector and not a scalar like the dot product.
◼
The magnitude of the cross product is the same as ||v||*||u||*sin(θ) where θ is the angle between the two vectors.
This is the same as
◼
Let’s see what these three vectors look like.
◼
The cross product is the same as finding the determinant of the matrix
where i, j, and k are the x, y, and z unit vectors respectively. The result of the cross product of vector {1,0,0} and {0,1,0} is {0,0,1}, or k.
◼
Unlike the dot product, the order of vectors in a cross product does matter.
◼
While order matters, the result of changing the order will be the same vector multiplied by -1.
◼
Now let’s do flip the order and multiply by -1.
We can see the results are the same. That’s all there is to know about basic Euclidean vectors!
